Rem 487
Vehicle type:
Registration country:
Railway companies:
Gauge:
Standard gauge (1'435 mm)
Wheel arrangement:
Bo'Bo'
Electric systems:
25 kV AC / 50 Hz
15 kV AC / 16,7 Hz
15 kV AC / 16,7 Hz
Current collectors:
Pantograph - Asymmetrical
N° of pantographs:
4
Length over buffers (mm):
18900
Width (mm):
2977
Height (mm | over lowered pantograph):
4283
Wheelbase (distance between bogies centers) (mm):
10440
Tare weight (t):
87
Axle load (t):
22
Power output (x'xxx kW / x'xxx hp):
5600
Tractive effort (kN / lbf | starting / continuous):
300
Last Mile power output (kW / hp):
180
Last Mile tractive effort (kN / lbf):
300
Last Mile fuel tank volume (l):
400
Bogie wheelbase (mm):
2600
Wheel diameter (x'xxx,xx | mm | new / worn):
1250
Maximum speed (km/h):
160
