CC 70000
Vehicle type:
Registration country:
Railway companies:
In service:
from 1965
Era:
III - IV
Built by:
Gauge:
Standard gauge (1'435 mm)
Wheel arrangement:
C'C'
Length over buffers (mm):
22'730 mm
Width (mm):
2'900 mm
Height (mm | over lowered pantograph):
4'200 mm
Wheelbase (distance between bogies centers) (mm):
15'916 mm
Tare weight (t):
117 t
Power output (x'xxx kW / x'xxx hp):
3'000 kW
Wheel diameter (x'xxx,xx | mm | new / worn):
1'050 mm
Maximum speed (km/h):
140 km/h
1961
1961--01
