BCYMD/MOT
Also known as:
Sentinel-Cammell 6-axles
Vehicle type:
Registration country:
Railway companies:
In service:
from 1933
Length over buffers (mm):
33'833 mm
Distance between powered bogies centers (mm):
13'919 mm
Tare weight (t):
56,188 t
Service weight (t):
61,877 t
Number of driven axles:
2x driven axles*
*there are 2x driven boggies, each having 1x driven axle
*there are 2x driven boggies, each having 1x driven axle
Water tank capacity (kg / l / m³):
910 l*
*providing an autonomy of 200 km
3'640 l*
*providing an autonomy of 100 km
*providing an autonomy of 200 km
3'640 l*
*providing an autonomy of 100 km
Bogie wheelbase (mm):
2'286 mm*
*driven bogie
1'981*
*carrier bogie
*driven bogie
1'981*
*carrier bogie
Wheel diameter (x'xxx,xx | mm | new / worn):
955 mm
Maximum speed (km/h):
90 km/h*
**75 km/h maximum permissible speed on the Romanian Railways network
**75 km/h maximum permissible speed on the Romanian Railways network
Total number of seats (1st class seats / 2nd class seats / 3rd class seats / folding seats):
110x seats (28x 2nd class seats and 82x 3rd class seats)
1933
1933--01
