Length over buffers (mm):
9'190 mm
Width (mm):
3'100 mm
Height (mm | over lowered pantograph):
4'040 mm
Wheelbase (mm | rigid / total):
5'000 mm
Minimum radius of curvature on open stretches (m):
150 m
Minimum radius of curvature on switching sections (m):
75 m
Tare weight (t):
12,85 t
Maximum load weight (t):
27 t
Wheel diameter (x'xxx,xx | mm | new / worn):
1'000 mm
Maximum speed (km/h):
100 km/h
Braking system (vacuum brakes / air brakes / electropneumatic brakes / electronically controlled pneumatic brakes / electric brakes - tread (clasp) brakes / axle-mounted disk brakes / wheel-mounted disk brakes / dynamic brakes / regenerative brakes / rail brakes):
KE-GP
Maximum load volume (m³):
25 m³
1972
1972--01
