PAz 20,28 m (21,60 m)
Also known as:
PAmyi 20,28 m (21,60 m)PAyi 20,28 m (21,60 m)OCEM Ra 26/29Type 1926
UIC / EVN numbering:
50 87 00-3750 87 00-4750 87 00-7750 87 00-87Vehicle type:
Registration country:
Railway companies:
In service:
from 1928
Length over buffers (mm):
21'570 mm
Width (mm):
2'960 mm
Height (mm | over lowered pantograph):
4'068 mm
Wheelbase (distance between bogies centers) (mm):
14'680 mm
Tare weight (t):
41 - 43 t
Maximum load weight (t):
8 t
Bogies:
Y2
Y24 Z
Y24 JZ
Y24 Z
Y24 JZ
Maximum speed (km/h):
140 km/h*
*Y2 bogies
160 km/h*
*Y24 Z and Y24 JZ bogies
*Y2 bogies
160 km/h*
*Y24 Z and Y24 JZ bogies
Access doors width (mm):
1'060 mm
Access doors height (mm):
1'880 mm
